EB/EBC系列柴油機泵/泵組是本公司最新推出的新型泵系列產品。主要適用于化工、輕工、建筑、灌溉、水循環系統、冷卻水循環系統。也可用于水上船舶、海上油輪和水上艦艇等場合。水泵機組采用優質柴油機與水泵配套，具有移動方便、聯接緊固、啟動迅速、引水快捷、功率儲備合理、運行平穩等特點，是一種先進可靠的輸送設備。
EB series mini manual cast iron hand water pump
| Pump type | EB series diesel engine centrifugal water pump |
| Casing | Cast Iron |
|
Casing Cover |
Cast Iron |
| Impeller | Cast Iron |
|
Shaft Sleeve |
Bronze |
| Mechanical Seal | Graphite-Ceramic/Viton |
|
Suction/Discharge port dia |
50mm(EB20),80mm(EB30) |
| Max.capacity(m3/hr) | 35(EB20),40(EB30) |
| Max.Head(m) | 56(EB20),77(EB30) |
| Engine Speed(rpm) | 3600 |
| Net Weight(kg) | 11(EB20),21(EB30) |
| Dimension(L×W×H)(mm) | 285×245×125(EB20),340×305×185(EB30) |
| Advantage | Coupled with high quality diesel engine,easy to be moved and utilized compared by fixed pump set.launched and draw water very quickly,also its running is very smooth. |
| Applications | Chemical industry,light industry,construction,irrigation and water circulating system,ships,oil tanks and other vessels as a kind of advanced and reliable conveying equipments,etc. |
| Coupled with Diesel Engine | |
| Engine Model | 178F | 186F |
| Rated output(kw) |
3.7 |
5.7 |
| Displacement (cc) | 296 | 406 |
| Fuel tank capacity(L) | 3.5 | 5.5 |
| Net weight(kg) | 47 | 70 |
| Dimension(L×W×H)(mm) | 450×470×560 | 550×480×600 |
